Neoprene Rubber Gasket Material Manufacturer | Bulk Rubber Gasket Sheet 3mm Price
Base Polymer: Neoprene (Chloroprene Rubber - CR / Industrial Compound Blend)
Color: Deep Black
Thickness Range: 1mm to 20mm (With optimized precision calandering for standard industrial 3mm requirements)
Standard Roll Dimensions:
Width: 1.0m / 1.2m / 1.4m / 1.5m / 2.0m
Length: 5m / 10m / 15m / 20m (Custom roll lengths and master log splitting available for bulk contract orders).
Surface Finish: Smooth finish on both sides, fabric impression (single or double-sided), or non-slip textured profiles.
Supply Formats: Continuous Master Rolls, Slit Strips, or Die-Cut Custom Blanks.
Reinforcement Layers: Available with high-tensile Nylon cloth insertion, Polyester mesh, or heavy-duty multi-ply fabric matrixing.
Export Packaging & Logistics: Standard global export protection including heavy-duty moisture-proof plastic film, woven PP bags, and secure fumigated wood/plastic paletization. Custom branding, private labeling, and specialized batch marking are fully supported for global distributors.
Factory Bulk Supply: High-Resilience Neoprene Rubber Gasket Material
Our commercial and premium-grade neoprene rubber gasket material is engineered specifically for industrial fabricators, gasket die-cutters, and international industrial supply distributors who demand reliable sealing performance under diverse operational conditions. Formulated with high-quality chloroprene synthetic rubber compounds, our sheets provide a well-balanced resistance to moderate oils, petroleum products, ozone weathering, UV exposure, and natural aging. This multi-environment versatility makes it the premier choice for sealing applications across the marine, automotive, HVAC, and general industrial engineering sectors.
For procurement managers evaluating the global market for a competitive rubber gasket sheet 3mm price, our factory offers an optimized production matrix that balances high physical integrity with volume-based cost efficiencies. The 3mm thickness represents the global standard for heavy-duty pipe flange gaskets, electrical enclosure seals, and machinery anti-vibration padding. With a controlled density of 1.4g/cm³ to 1.5g/cm³ and a standard nominal hardness of 65 Shore A, our calandered neoprene sheets offer ideal compressibility and excellent torque retention, ensuring long-lasting, leak-free configurations.
As a dedicated wholesale manufacturing facility, we ensure exceptional gauge consistency and smooth surface finishes across every single production run. Our master rolls are structurally optimized for high-speed automated CNC flatbed cutting, waterjet processing, or conventional die-stamping. By sourcing direct from our factory via Full Container Loads (FCL) or structured Less than Container Loads (LCL), industrial buyers can stabilize their supply chains, safeguard their technical margins, and guarantee consistent lot-to-lot performance for their local distribution networks.
Neoprene CR Material Specification & Physical Properties
| Product Code | Specific Gravity (Density) | Nominal Hardness | Tensile Strength | Elongation at Break |
|---|---|---|---|---|
| ZXZRS20101C | 1.45 g/cm³ | 60 +/-5 Shore A | 5.0 MPa | 280% |
Standard Thickness Grade & Theoretical Weight Matrix
| Thickness (mm) | Standard Roll Width | Standard Roll Length | Reinforcement / Insertion Options | Theoretical Mass Weight |
|---|---|---|---|---|
| 1.0 mm | 1.2 m | 10 m | Non-reinforced (Smooth) | 13.92 kg/roll |
| 2.0 mm | 1.2 m | 10 m | Available in 1 PLY Cloth Inserion | 31.32 kg/roll |
| 3.0 mm | 1.2 m / 1.5 m | 10 m | Smooth / 1 PLY Nylon Reinforced | 48.72 kg/roll (1.2M) |
| 4.0 mm | 1.2 m | 10 m | Smooth / 1-2 PLY Cloth Insertion | 66.12 kg/roll |
| 5.0 mm | 1.2 m / 1.5 m | 10 m | Smooth / Up to 2 PLY Reinforcement | 83.52 kg/roll |
| 6.0 mm | 1.2 m | 10 m | Smooth / Up to 3 PLY Reinforcement | 100.92 kg/roll |
| 8.0 mm | 1.2 m | 10 m | Smooth / Multi-PLY Cloth Matrix | 135.72 kg/roll |
| 10.0 mm | 1 m | 5 m / 10 m | Smooth / Multi-PLY Cloth Matrix | 145 kg/roll |
| 15.0 mm | 1.0 m | 5 m | Heavy-duty calandered slab | 108.75 kg/roll |
| 20.0 mm | 1.0 m | 5 m | Heavy-duty calandered slab | 145 kg/roll |
1. All sizing values and dimensional capacities listed above conform to standardized international rubber calandering manufacturing tolerances (±).
2. Physical test values represent standard industrial averages obtained in laboratory conditions; actual material lots follow stable commercial compliance bands.
3. Custom roll lengths, slitting widths, and alternative mechanical properties are available under specialized contract manufacturing requests.
4. Theoretical mass weights are calculated based strictly on the 1.45g/cm³ commercial density index. Incorporting internal fabric reinforcements or selecting higher-grade CR polymers will cause variance in final roll weights.
Commercial Bulk Supply Agreement Terms
Operating exclusively as an industrial elastomeric manufacturing facility, our output is strictly reserved for high-volume corporate supply chains, commercial material distributors, international wholesalers, and large-scale industrial conversion plants. We execute production under minimum order quantities (MOQ) or full shipping container metrics to ensure the most cost-competitive, direct-from-factory cost structures for our global export partners.
* Strategic Limitation Note: Our corporate focus centers entirely on advanced compound formulation, industrial calandering production, and direct supply of bulk rubber rolls and slabs. We do not provide technical field engineering, physical site installation, onsite machinery maintenance, or retail consumer services.
