Hardness 60 CR Neoprene black rubber sheeting
Polymer: Neoprene rubber
Color: Black
Thickness: 3mm
Standard Size:
Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.
Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.
Customizable Shapes: Roll / Sheet / Strip
Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas
Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.
CR Rubber Sheet Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation at Break |
| ZXZRS20101C-60 | 1.45g/cm³ | 60+/-5 Shore A | 4-5Mpa | 260% |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1.2m | 10m | / | 13.92kgs/m² |
| 1.5 | 1.2m | 10m | / | 22.62kgs/m² |
| 2 | 1.2m | 10m | 1PLY | 31.32kgs/m² |
| 3 | 1.2m | 10m | 1PLY | 48.72kgs/m² |
| 4 | 1.2m | 10m | 1PLY | 66.12kgs/m² |
| 5 | 1.2m | 10m | 2PLY | 83.52kgs/m² |
| 6 | 1.2m | 10m | 3PLY | 100.92kgs/m² |
| 8 | 1.2m | 10m | 4PLY | 135.72kgs/m² |
| 10 | 1.2m | 10m | 5PLY | 170.52kgs/m² |
| 12 | 1m | 10m | 8PLY | 174kgs/m² |
| 15 | 1m | 10m | 10PLY | 217.5kgs/m² |
| 20 | 1m | 2m | 10PLY | 58kgs/m² |
1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.
Chemical Properties
| Polymer content | ZXZRS20001PC-20% | ZXZRS20001PC-30% | ZXZRS20001PC-50% | ZXZRS20001PC-70% | ZXZRS20001PC-100% |
| Aliphatic Hydrocarbons | Regular | Regular | Excellent | Excellent | Excellent |
| Aromatic Hydrocarbons | Regular | Regular | Excellent | Excellent | Excellent |
| Lubricating Oils | Regular | Regular | Regular | Regular | Excellent |
| Outdoor Exposure | Regular | Regular | Regular | Excellent | Excellent |
| Ozone Exposure | Regular | Regular | Regular | Excellent | Excellent |
| Diluted Acids | Regular | Regular | Regular | Excellent | Excellent |
| Diluted Alkali | Regular | Regular | Regular | Excellent | Excellent |
| Vegitable Oil | Poor | Poor | Regular | Excellent | Excellent |
| Animal Oil | Poor | Poor | Regular | Excellent | Excellent |
Note:
1. The chemical resistance values provided are intended as general reference only, based on standard laboratory conditions.
2. Actual performance may vary depending on chemical concentration, temperature, exposure time, and specific working conditions.
3. It is the responsibility of the user to verify material compatibility before application.
4. The manufacturer assumes no liability for damages or failures resulting from improper material selection or usage conditions.
5. Detailed technical advice are available upon request.
Black neoprene rubber sheet offers balanced resilience and moderate hardness, making it ideal for general-purpose sealing and cushioning applications. At 60 Shore A and 1.45 density, it ensures dependable mechanical strength while remaining flexible enough for shaping and trimming. Often selected for low-pressure flange sealing, industrial gaskets, and protective pads, this neoprene rubber gasket sheet performs well where weather resistance is not the primary concern but dimensional stability and moderate durability are required. Supplied in 1/8 inch neoprene rubber sheet format, it’s easy to fabricate into custom profiles or strips as needed.
