Product
Hardness 55 Neoprene black rubber sheet 1.3 gravity
Polymer: Neoprene rubber
Color: Black
Thickness: 3mm
Standard Size:
Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.
Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.
Customizable Shapes: Roll / Sheet / Strip
Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas
Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.
Neoprene Rubber Sheet Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strenth | Elongation at Break |
| ZXZRS20101C-55 | 1.5g/cm³ | 55+/-5 Shore A | 8Mpa | 400% |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1.5m | 10m | / | 15.6kgs/m² |
| 1.5 | 1.5m | 10m | / | 25.35kgs/m² |
| 2 | 1.5m | 10m | 1PLY | 35.1kgs/m² |
| 3 | 1.5m | 10m | 1PLY | 54.6kgs/m² |
| 4 | 1.5m | 10m | 1PLY | 74.1kgs/m² |
| 5 | 1.5m | 10m | 2PLY | 93.6kgs/m² |
| 6 | 1.5m | 10m | 3PLY | 113.1kgs/m² |
| 8 | 1.5m | 10m | 4PLY | 152.1kgs/m² |
| 10 | 1.5m | 10m | 5PLY | 191.1kgs/m² |
| 12 | 1m | 2m | 8PLY | 31.2kgs/m² |
| 15 | 1m | 2m | 10PLY | 39kgs/m² |
| 20 | 1m | 2m | 10PLY | 52kgs/m² |
| 25 | 1m | 2m | 10PLY | 65kgs/m² |
| 30 | 1m | 2m | 10PLY | 78kgs/m² |
1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.
Chemical Properties
| Polymer content | ZXZRS20001PC-20% | ZXZRS20001PC-30% | ZXZRS20001PC-50% | ZXZRS20001PC-70% | ZXZRS20001PC-100% |
| Aliphatic Hydrocarbons | Regular | Regular | Excellent | Excellent | Excellent |
| Aromatic Hydrocarbons | Regular | Regular | Excellent | Excellent | Excellent |
| Lubricating Oils | Regular | Regular | Regular | Regular | Excellent |
| Outdoor Exposure | Regular | Regular | Regular | Excellent | Excellent |
| Ozone Exposure | Regular | Regular | Regular | Excellent | Excellent |
| Diluted Acids | Regular | Regular | Regular | Excellent | Excellent |
| Diluted Alkali | Regular | Regular | Regular | Excellent | Excellent |
| Vegitable Oil | Poor | Poor | Regular | Excellent | Excellent |
| Animal Oil | Poor | Poor | Regular | Excellent | Excellent |
Note:
1. The chemical resistance values provided are intended as general reference only, based on standard laboratory conditions.
2. Actual performance may vary depending on chemical concentration, temperature, exposure time, and specific working conditions.
3. It is the responsibility of the user to verify material compatibility before application.
4. The manufacturer assumes no liability for damages or failures resulting from improper material selection or usage conditions.
5. Detailed technical advice are available upon request.
Manufactured with a low specific gravity of 1.3 and Shore A hardness of 55, this neoprene rubber material stands out for its superior flexibility and lightweight structure. Neoprene rubber material is especially suitable for applications that require pliable and form-fitting seals, such as low-pressure gaskets, vibration isolation pads, and lining jobs where ease of installation is key. As a china neoprene rubber sheet supplier, we focus on offering consistent quality across every roll. This black neoprene rubber material exhibits stable mechanical properties and maintains resilience even under moderate compression or repeated bending.
The fine surface finish, uniform thickness, and low-tack texture make this neoprene sheet material easy to cut and bond with adhesives. Whether you're converting it into strips, washers, or sheets for padding, it performs reliably in both industrial and commercial settings.
Key Features
Density: 1.3, ensuring a lightweight yet durable profile
Soft 55 Shore A hardness for excellent flexibility
Easy to die-cut or CNC-process into gaskets or linings
Stable physical properties across different temperatures
Matte black surface with uniform thickness throughout
Bulk rolls available for OEM and fabrication use
