Hardness 55 Black CR rubber sheeting roll 1.35 gravity
Premium Neoprene Rubber Sheet - Factory Direct Supply
As a leading neoprene sheet factory, we provide high-performance sealing and cushioning solutions tailored for industrial requirements. Our neoprene rubber sheet 1/16 inch is specifically engineered for versatility, offering a balance of flexibility, chemical resistance, and durability. Whether you require standard neoprene sheet black material for gaskets or bulk neoprene rolls for large-scale production, our factory ensures consistent thickness, uniform surface quality, and reliable material integrity.
Product Technical Specifications
Polymer: Neoprene rubber
Color: Black (Neoprene sheet black)
Thickness: 1.5mm (approx 1/16")
Customizable Shapes: Roll / Sheet / Strip
Embedding layer: Nylon canvas / Mesh fabric / Encrypted canvas
Surface: Smooth, Cloth-inserted, or Anti-slip
Standard Size: Width: 1m - 2m; Length: 5m - 20m; Custom dimensions available.
Packing Info: Custom packing includes plastic film, PP bags, and pallets. Color, logo, and labels can be customized upon request.
CR Rubber Sheet Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation at Break |
| ZXZRS20101C-55 | 1.35g/cm³ | 55+/-5 Shore A | 6-7Mpa | 350% |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1m | 15m | / | 10.8kgs/m² |
| 1.5 | 1m | 15m | / | 17.55kgs/m² |
| 2 | 1m | 15m | 1PLY | 24.3kgs/m² |
| 3 | 1m | 15m | 1PLY | 37.8kgs/m² |
| 4 | 1m | 15m | 1PLY | 51.3kgs/m² |
| 5 | 1m | 15m | 2PLY | 64.8kgs/m² |
| 6 | 1m | 15m | 3PLY | 78.3kgs/m² |
| 8 | 1m | 15m | 4PLY | 105.3kgs/m² |
| 10 | 1m | 15m | 5PLY | 135kgs/m² |
| 12 | 1m | 2m | 6PLY | 32.4kgs/m² |
| 15 | 1m | 2m | 8PLY | 40.5kgs/m² |
| 20 | 1m | 2m | 10PLY | 54kgs/m² |
| 25 | 1m | 2m | 10PLY | 67.5kgs/m² |
Chemical Properties
| Polymer content | ZXZRS20001PC-20% | ZXZRS20001PC-30% | ZXZRS20001PC-50% | ZXZRS20001PC-70% | ZXZRS20001PC-100% |
| Aliphatic Hydrocarbons | Regular | Regular | Excellent | Excellent | Excellent |
| Aromatic Hydrocarbons | Regular | Regular | Excellent | Excellent | Excellent |
| Lubricating Oils | Regular | Regular | Regular | Regular | Excellent |
| Outdoor Exposure | Regular | Regular | Regular | Excellent | Excellent |
| Ozone Exposure | Regular | Regular | Regular | Excellent | Excellent |
| Diluted Acids | Regular | Regular | Regular | Excellent | Excellent |
| Diluted Alkali | Regular | Regular | Regular | Excellent | Excellent |
| Vegitable Oil | Poor | Poor | Regular | Excellent | Excellent |
| Animal Oil | Poor | Poor | Regular | Excellent | Excellent |
Neoprene rubber sheet 1/16 inch thick, manufactured with a specific gravity of 1.35 and Shore A hardness of 55, offers a soft, lightweight solution for cushioning and sealing needs. As a flexible material with good compressibility, it's well-suited for making gaskets, lining surfaces, and absorbing vibration in light-duty industrial environments. We supply this material as part of our standard neoprene rolls, ensuring easy transport, efficient storage, and convenient processing.
As a professional neoprene sheet factory, we maintain strict control over sheet uniformity and surface quality, allowing it to perform reliably in repeated-use or indoor applications. The neoprene sheet black finish ensures a neutral appearance for general use and blends well in automotive, electronic, and packaging applications.
