Industrial SBR 5mm Rubber Gasket Sheet for Die-Cutting
Polymer: Styrene Butadiene rubber
Color: Black
Thickness: 1mm to 100mm; above 15mm offered in sheet form.
Standard Size: Width: 1m, 1.2m, 1.4m, 1.5m, 1.6m, 1.8m, 2.0m; Length: 5m, 10m, 15m, 20m; Custom dimensions available.
Customizable Shapes: Roll / Sheet / Strip
Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.
Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas
Packing Info: Custom packing includes plastic film, PP bags, and pallets. Color, logo, and labels or special markings can be customized upon request.
SBR Sheet Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation |
| ZXZRS20101S-60 | 1.4g/cm³ | 60+/-5 Shore A | 5-6Mpa | 300% |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1.2m | 15m | / | 20.16kgs/m² |
| 1.5 | 1.2m | 15m | / | 32.76kgs/m² |
| 1.7 | 1.2m | 15m | 1PLY | 37.8kgs/m² |
| 2 | 1.2m | 15m | 1PLY | 45.36kgs/m² |
| 3 | 1.2m | 15m | 1PLY | 70.56kgs/m² |
| 4 | 1.2m | 15m | 1PLY | 95.76kgs/m² |
| 5 | 1.2m | 15m | 2PLY | 120.96kgs/m² |
| 6 | 1.2m | 15m | 3PLY | 146.16kgs/m² |
| 7 | 1.2m | 15m | 4PLY | 171.36kgs/m² |
| 8 | 1.2m | 15m | 4PLY | 196.56kgs/m² |
| 9 | 1.2m | 15m | 4PLY | 221.76kgs/m² |
| 10 | 1.2m | 15m | 5PLY | 246.96kgs/m² |
| 12 | 1m | 2m | 8PLY | 33.6kgs/m² |
| 15 | 1m | 2m | 10PLY | 42kgs/m² |
| 20 | 1m | 2m | ≥10PLY | 56kgs/m² |
| 25 | 1m | 2m | ≥10PLY | 70kgs/m² |
Tianjin China Rubber Co.,Ltd: SBR Rubber Technical Excellence
At Tianjin China Rubber Co.,Ltd, our 5mm SBR (Styrene Butadiene Rubber) gasket sheets are engineered to provide exceptional mechanical performance and versatility for a wide array of industrial applications. With a precisely calibrated specific gravity of 1.40 and a Shore A hardness of 60, these sheets represent an ideal equilibrium between structural rigidity and necessary elasticity. This grade offers a notable advantage in material handling: while providing the stability required for heavy-duty sealing, it remains remarkably flexible, allowing for seamless adaptation to uneven surfaces or complex flange geometries without risking structural fatigue.
Our commitment at Tianjin China Rubber Co.,Ltd is to deliver consistent, high-quality material integrity. Unlike denser, more rigid variants, this 60 Shore A grade effectively mitigates vibration, acting as a reliable dampener in machinery environments. It excels as an industrial gasket, vibration isolation barrier, or protective padding in settings where extreme oil and chemical exposure are not the primary environmental hazards. The sheet's surface remains smooth and dimensionally stable under significant compressive pressure, ensuring a dependable seal for indoor production lines, transit assembly zones, or as durable temporary protective flooring.
Tianjin China Rubber Co.,Ltd prioritizes manufacturing excellence. We subject every batch to rigorous quality control checks to ensure consistent thickness across the entire roll. Our materials are highly receptive to precision CNC die-cutting and professional-grade stamping, meaning that whether you require circular gaskets, custom-shaped strips, or irregular protective plates, the final product will retain the high fidelity of your original design specifications. By selecting our SBR series, you are investing in a product that combines operational longevity with structural consistency, perfectly suited for the evolving demands of modern global industrial manufacturing environments.
Key Features
- Optimized 60 Shore A hardness provides excellent flexibility with consistent structural rebound.
- Superior ease of handling, cutting, and layering for bespoke gasket production and site-specific protective applications.
- Manufactured by Tianjin China Rubber Co.,Ltd with strict adherence to industrial standards for longevity and reliability.
- Excellent for vibration isolation and noise reduction in heavy-duty machinery assembly zones.
