Product
Hardness 55 SBR black rubber sheet roll 1.35 Gravity
Polymer: Styrene Butadiene rubber
Color: Black
Thickness: Thickness ranges from 1mm to 100mm; above 15mm offered in sheet form.
Standard Size:
Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.
Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.
Customizable Shapes: Roll / Sheet / Strip
Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas
Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.
SBR Solid Rubber Roll Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation at Break |
| ZXZRS20101S-55 | 1.35 | 55+/-5 | 6-7 | 350% |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1.2m | 10m | / | 12.96kgs/m² |
| 1.5 | 1.2m | 10m | / | 21.06kgs/m² |
| 1.7 | 1.2m | 10m | 1PLY | 24.3kgs/m² |
| 2 | 1.2m | 10m | 1PLY | 29.16kgs/m² |
| 3 | 1.2m | 10m | 1PLY | 45.36kgs/m² |
| 4 | 1.2m | 10m | 1PLY | 61.56kgs/m² |
| 5 | 1.2m | 10m | 2PLY | 77.76kgs/m² |
| 6 | 1.2m | 10m | 3PLY | 93.96kgs/m² |
| 8 | 1.2m | 10m | 4PLY | 126.36kgs/m² |
| 10 | 1m | 2m | 5PLY | 158.76kgs/m² |
| 12 | 1m | 2m | 8PLY | 32.4kgs/m² |
| 15 | 1m | 2m | 10PLY | 40.5kgs/m² |
| 20 | 1m | 2m | ≥10PLY | 54kgs/m² |
| 30 | 1m | 2m | ≥10PLY | 81kgs/m² |
1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.
This solid rubber roll is manufactured from SBR and features a 2mm thickness, making it a practical choice for protective linings, lightweight gasketing, and general industrial buffering tasks. With a Shore A hardness of 55 and a specific gravity of 1.35, adding improved surface contact and compression feedback during assembly. The 2mm rubber sheet roll is uniform surface and flexible structure enable precise die-cutting or manual trimming for custom applications. It performs reliably in environments free from oil or aggressive chemicals, maintaining structural integrity under routine pressure. Produced in accordance with ASTM standards and verified by SGS, REACH, and RoHS2.0 certifications, this 2mm rubber sheet roll is suitable for indoor manufacturing and maintenance needs that require moderate elasticity and consistent thickness.
This solid rubber roll is well-suited for applications that demand thin, flexible protection—such as custom seals, vibration-dampening pads, and lightweight insulation layers. Its soft 55 Shore A hardness and slightly denser 1.35 g/cm³ body make it effective in precision gasket fabrication, especially where a 2mm rubber sheet roll is preferred for layering or non-structural separation. Commonly used in mechanical workshops, light assembly lines, packaging equipment bases, and dustproof enclosures.
