Product
Hardness 70 EPDM fabric reinforced rubber strips roll
Polymer: Ethylene Propylene Diene Monomer rubber
Color: Black
Thickness: Thickness ranges from 1mm to 100mm
Standard Size:
Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.
Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.
Customizable Shapes: Roll / Sheet / Strip
Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas
Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.
Fabric Reinforced Rubber Strips Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation at Break |
| ZXZRS20109F-70 | 1.6+/-0.05g/cm³ | 70+/-5 Shore A | 2.5-3Mpa | 180% |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1.5m | 5m | / | 9.6kgs/m² |
| 1.5 | 1.5m | 5m | / | 15.6kgs/m² |
| 1.7 | 1.5m | 5m | 1PLY | 18kgs/m² |
| 2 | 1.5m | 5m | 1PLY | 21.6kgs/m² |
| 3 | 1.5m | 5m | 1PLY | 33.6kgs/m² |
| 4 | 1.5m | 5m | 1PLY | 45.6kgs/m² |
| 5 | 1.2m | 10m | 2PLY | 57.6kgs/m² |
| 6 | 1.5m | 5m | 3PLY | 69.6kgs/m² |
| 8 | 1.5m | 5m | 4PLY | 93.6kgs/m² |
| 10 | 1.5m | 5m | 5PLY | 120kgs/m² |
| 12 | 1m | 2m | 8PLY | 38.4kgs/m² |
| 15 | 1m | 2m | 10PLY | 48kgs/m² |
| 25 | 1m | 2m | 10PLY | 80kgs/m² |
1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.
Reinforced EPDM sheet is designed for high-performance sealing and isolation applications where durability and environmental resistance are critical. Manufactured using high-quality EPDM rubber and strengthened with embedded fabric layers, the product maintains consistent mechanical strength under compression, bending, or elongation. With a density of 1.6 g/cm³ and a Shore A hardness of 70, this reinforced rubber strip delivers excellent resistance to weathering, ozone, and aging—making it a reliable solution for both indoor and outdoor installations. The fabric layer prevents stretching and tearing, helping the strip maintain its dimensional stability even under frequent movement or mechanical stress.
These fabric reinforced rubber strips are commonly used in automotive sealing, machinery skirting, protective edging, and as flexible barriers in HVAC or construction applications. The robust internal reinforcement makes them suitable for mounting surfaces that undergo repeated tension, while the EPDM compound offers long-lasting elasticity and heat resistance. Whether cut into narrow reinforced rubber strips or used as broader sealing sheets, this reinforced EPDM sheet maintains its form and function over time. It is ideal for customers requiring fabric reinforced rubber strips that combine flexibility with structural integrity.
