Hardness 55 Black natural strip insertion rubber roll
Polymer: Natural rubber
Color: Black
Thickness: 10mm
Standard Size:
Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.
Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.
Customizable Shapes: Roll / Sheet / Strip
Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas
Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.
Fabric Reinforced Rubber Strips Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation at Break |
| ZXZRS20109F-55 | 1.3+/-0.05g/cm³ | 55+/-5 Shore A | 8Mpa | 400% |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1.5m | 5m | / | 7.8kgs/m² |
| 1.5 | 1.5m | 5m | / | 12.7kgs/m² |
| 1.7 | 1.5m | 5m | 1PLY | 14.63kgs/m² |
| 2 | 1.5m | 5m | 1PLY | 18kgs/m² |
| 3 | 1.5m | 5m | 1PLY | 27.3kgs/m² |
| 4 | 1.5m | 5m | 1PLY | 37.05kgs/m² |
| 5 | 1.2m | 10m | 2PLY | 46.8kgs/m² |
| 6 | 1.5m | 5m | 3PLY | 57kgs/m² |
| 8 | 1.5m | 5m | 4PLY | 76.05kgs/m² |
| 10 | 1.5m | 5m | 5PLY | 97.5kgs/m² |
| 12 | 1m | 2m | 8PLY | 31.2kgs/m² |
| 15 | 1m | 2m | 10PLY | 39kgs/m² |
| 25 | 1m | 2m | 10PLY | 65kgs/m² |
1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.
Natural insertion rubber is made from high-quality natural rubber compounded with a reinforcing fabric layer to improve mechanical strength while maintaining excellent flexibility. With a density of 1.3 g/cm³ and hardness of 55 Shore A, it is particularly well-suited for dynamic applications that demand both resilience and softness. The embedded cloth reinforcement enhances tear resistance and dimensional stability, making this natural insertion rubber ideal for applications involving repeated movement or compression. The product is frequently supplied in 10mm insertion rubber format, providing an optimal thickness for vibration isolation, sealing, and protective linings.
Because of its high elasticity and grip, this natural strip insertion rubber is often used in workshop flooring, conveyor belt skirting, anti-slip padding, and protective edge strips. It withstands friction, low-temperature bending, and mechanical stress while remaining easy to cut and shape. Available in continuous rolls or strips, the natural insertion rubber is a dependable choice for customers who require soft yet reinforced material. The 10mm insertion rubber format balances flexibility and durability, while the natural strip insertion rubber provides excellent grip and deformation resistance.
