Product

Neoprene high content UV resistance rubber
Neoprene high content UV resistance rubber
Neoprene high content UV resistance rubber
Neoprene high content UV resistance rubber
Neoprene high content UV resistance rubber
Neoprene high content UV resistance rubber

Neoprene high content UV resistance rubber

ZXZRS20011AR
Neoprene rubber sheet resistant to sunlight, ozone, and outdoor aging. Ideal for sealing and insulation uses where neoprene uv resistance is required.

Polymer: Neoprene rubber

Color: Black

Thickness: Thickness ranges from 1mm to 100mm; above 15mm offered in sheet form.

Standard Size:

Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.

Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.

Customizable Shapes: Roll / Sheet / Strip

Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas

Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.





Neoprene UV Resistance Performance Parameters & Specification

Code Specific Gravity Hardness Tensile Strength Elongation at Break
ZXZRS20011CR-PC100% 1.3g/cm³ 60+/-5 Shore A 10-12Mpa 420%
ZXZRS20011CR-PC70% 1.3g/cm³ 60+/-5 Shore A 9-10Mpa 380%
ZXZRS20011CR-PC50% 1.4g/cm³ 60+/-5 Shore A 7-8Mpa 320%
ZXZRS20011CR-PC30% 1.4g/cm³ 60+/-5 Shore A 5Mpa 280%
Thickness Width Length Insertion Weight
1 1m 10m / 10.4kgs/m²
1.5 1m 10m / 16.9kgs/m²
1.7 1m 10m 1PLY 19.5kgs/m²
2 1m 10m 1PLY 23.4kgs/m²
3 1m 10m 1PLY 36.4kgs/m²
4 1m 10m 1PLY 49.4kgs/m²
5 1m 10m 2PLY 62.4kgs/m²
6 1m 10m 3PLY 75.4kgs/m²
8 1m 10m 4PLY 101.4kgs/m²
10 1m 10m 5PLY 130kgs/m²
12 1m 2m 8PLY 31.2kgs/m²
15 1m 2m 10PLY 39kgs/m²
20 1m 2m ≥10PLY 52kgs/m²
25 1m 2m ≥10PLY 65kgs/m²

1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.

UV Resistance Properties

Polymer content ZXZRS20001PC-20% ZXZRS20001PC-30% ZXZRS20001PC-50% ZXZRS20001PC-70% ZXZRS20001PC-100%
Outdoor Exposure Regular Regular Regular Excellent Excellent
Ozone Exposure Regular Regular Regular Excellent Excellent

Note:
1. The chemical resistance values provided are intended as general reference only, based on standard laboratory conditions.
2. Actual performance may vary depending on chemical concentration, temperature, exposure time, and specific working conditions.
3. It is the responsibility of the user to verify material compatibility before application.
4. The manufacturer assumes no liability for damages or failures resulting from improper material selection or usage conditions.
5. Detailed technical advice are available upon request.



neoprene uv resistance



neoprene uv resistance



neoprene uv resistance



neoprene uv resistance



Neoprene rubber sheet offers excellent performance under prolonged exposure to outdoor environments. With high neoprene uv resistance, the material withstands ultraviolet rays and ozone without cracking, discoloration, or becoming brittle. The sheet maintains stable mechanical behavior across a wide temperature range, adapting well to both hot and cold climates. In outdoor electrical enclosures, equipment housing, and rooftop isolation pads, its resistance to sunlight and oxidation helps maintain the integrity of seals and insulation over time. Even in coastal or industrial zones where atmospheric conditions can be aggressive, the sheet continues to perform with minimal degradation.

As a synthetic rubber, neoprene naturally resists moderate oils, greases, and certain chemicals, further expanding its use in areas where occasional fluid contact may occur. Combined with its ozone and UV stability, the sheet is particularly suited for automotive components, outdoor gasketing, weather seals, and protective covers.

When high neoprene uv resistance is required, particularly for parts exposed to the elements year-round, this rubber sheet offers a practical and effective material choice. Consistent resilience under UV-rich conditions helps reduce the frequency of maintenance, while providing long-lasting sealing or cushioning in outdoor systems.

Neoprene sheets are available in various thicknesses and hardness options to meet different application needs. Whether installed in transportation infrastructure, energy equipment, or general industrial machinery, the sheet offers long-term protection against weathering and sun damage. Its combination of elasticity, UV shielding, and weather resistance makes it a common material in both static and mobile outdoor systems.
