Product
Black 3mm chequer plate rubber matting 1.5m width
Polymer: Synthetic rubber
Color: Black
Thickness: 3mm - 10mm
Standard Size:
Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.
Surface: one side is smooth, one sides with cloth
Customizable Shapes: Roll / Sheet
Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.
Antislip Rubber Sheet Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation at Break |
| ZXZRS20114AF-65 | 1.5g/cm³ | 65+/-5 Shore A | 3Mpa | 200% |
1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.
| Thickness | Design | Width | Length/Roll | Weight |
| 3mm |
|
1.2m | 10m | 50.40kgs/m² |
| 3mm | 1.5m | 10m | 63.00kgs/m² | |
| 3mm | 1.6m | 10m | 67.20kgs/m² | |
| 3mm | 1.8m | 15m | 113.40kgs/m² | |
| 3mm | 2.0m | 15m | 126.00kgs/m² | |
| 5mm |
|
1.2m | 10m | 86.40kgs/m² |
| 5mm | 1.5m | 10m | 108.00kgs/m² | |
| 5mm | 1.6m | 15m | 172.80kgs/m² | |
| 5mm | 1.8m | 10m | 129.60kgs/m² | |
| 5mm | 2.0m | 20m | 288.00kgs/m² |
* Color/size can be produced according to needs. For more specifications, please contact us
* Regarding the dimensions in the Design, please refer to the final production dimensions for reference only.
* There may be a slight difference between the weight of a single roll and the final delivery weight, which shall be subject to the final delivery purchase weight.
Chequer plate rubber matting features a raised five-bar pattern that provides excellent slip resistance for both pedestrian and light vehicle traffic. It is commonly used in walkways, workshops, loading docks, and trailers where enhanced surface grip is essential. The textured finish helps prevent accidents by increasing friction underfoot.
Checker plate matting made by Tianjin China Rubber Co.,Ltd is manufactured from industrial-grade rubber compounds, delivering stable performance in various environments. The design reduces the risk of slippage while also protecting flooring beneath from impact and abrasion. With customizable lengths and consistent quality, checker rubber matting adapts to different flooring applications with ease.
Chequer plate rubber matting also absorbs vibration and reduces noise, making it suitable for heavy-use areas. Its surface design maintains effectiveness over time, and the matting is easy to clean and maintain, even under frequent use.
