Product
Hardness 60 FDA Grade NBR white rubber sheet
Polymer: Nitrile rubber
Color: White
Thickness: Thickness ranges from 1mm to 30mm; above 15mm offered in sheet form.
Standard Size:
Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.
Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.
Customizable Shapes: Roll / Sheet / Strip
Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas
Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.
FDA Grade NBR Rubber Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation at Break |
| ZXZRS20308FG-60 | 1.5g/cm³ | 60+/-5Shore A | 5min | 400% |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1.2m | 10m | / | 14.4kgs/m² |
| 1.5 | 1.2m | 10m | / | 23.4kgs/m² |
| 1.7 | 1.2m | 10m | 1PLY | 27kgs/m² |
| 2 | 1.2m | 10m | 1PLY | 32.4kgs/m² |
| 3 | 1.2m | 10m | 1PLY | 50.4kgs/m² |
| 4 | 1.2m | 10m | 1PLY | 68.4kgs/m² |
| 5 | 1.2m | 10m | 2PLY | 86.4kgs/m² |
| 6 | 1.2m | 10m | 3PLY | 104.4kgs/m² |
| 7 | 1.2m | 10m | 4PLY | 122.4kgs/m² |
| 8 | 1.2m | 10m | 5PLY | 140.4kgs/m² |
| 10 | 1.2m | 10m | 8PLY | 180kgs/m² |
| 12 | 1.2m | 10m | 10PLY | 216kgs/m² |
| 15 | 1.2m | 10m | ≥10PLY | 270kgs/m² |
| 20 | 1m | 2m | ≥10PLY | 60kgs/m² |
| 25 | 1m | 2m | ≥10PLY | 75kgs/m² |
| 30 | 1m | 2m | ≥10PLY | 90kgs/m² |
1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.
White nitrile rubber sheet is formulated for food-grade applications requiring cleanliness and oil resistance. With its smooth surface and non-marking properties, the white nitrile sheet performs reliably in environments like food processing, pharmaceutical manufacturing, and cleanroom sealing. In addition to its visual cleanliness, the white nitrile rubber sheet offers good mechanical strength, flexibility, and consistent sealing under contact with oils and animal fats. It complies with FDA 21 CFR 177.2600 standards, making it suitable for direct food contact where hygiene is critical.
Available in standard and custom thicknesses, the white nitrile sheet maintains performance across a range of processing environments while meeting the necessary health and safety regulations.
