Product
3mm/5mmx1.2mx10m Rubber diamond plate flooring roll
Product Name: Anti-slip Willow-leaf Rubber Sheet / Diamond Plate Rolls
Material Polymer: High-quality SBR / NR / EPDM Blend
Pattern Design: Raised Willow-leaf (Diamond) pattern for multi-directional grip
Standard Thickness: 3mm, 4mm, 5mm, 6mm, 8mm (Up to 10mm)
Available Sizes:
Width: 1.0m to 2.0m
Length: 10m, 15m, 20m per roll
Customizable Shapes: Roll / Sheet / Custom Cut
Custom Service: Full OEM support for thickness, width, and hardness (Shore A 65 +/-5).
Packing Info: Standard export PP bags and pallets; customized logos available upon request.
High-Performance Rubber Diamond Plate Sheets for Industrial & Transport Safety
As a specialized manufacturer, Tianjin China Rubber Co., Ltd offers heavy-duty rubber diamond plate flooring for trailer and industrial workshop environments. This classic willow-leaf embossed pattern is engineered to provide essential anti-slip protection by maximizing the contact surface friction. Whether in wet, snowy, or oily conditions, our rubber diamond plate sheets ensure stable footing for personnel and secure placement for equipment.
Industrial Grade Trailer & Garage Flooring
Our rubber diamond plate flooring for trailer interiors is designed to endure extreme mechanical wear and heavy rolling loads. The high-density synthetic rubber blend provides superior tear resistance and shock absorption. It serves as an excellent protective barrier for the metal or wooden chassis of horse trailers, cargo vans, and delivery trucks, preventing long-term corrosion and physical damage.
Core Advantages of Willow-leaf Rubber Rolls
- Weather Resistance: Excellent stability against UV rays, ozone, and temperature changes, suitable for outdoor ramp use.
- Safety First: The raised diamond pattern offers multi-directional traction, minimizing workplace trip and slip hazards.
- Maintenance Friendly: These rubber diamond plate sheets are waterproof and easy to clean with basic pressure washing or detergents.
- Vibration Dampening: Ideal for lining toolboxes or van floors to reduce noise and protect cargo during transit.
Beyond transportation, these versatile rubber rolls are widely deployed in commercial kitchen pathways, loading docks, gym walkways, and public transport aisles. We support global logistics and provide tailored cutting services to meet specific project dimensions. Every production batch undergoes strict quality control to ensure compliance with international safety and durability standards.
Technical Specifications
| Property | Value Range | Test Method |
|---|---|---|
| Specific Gravity | 1.5g/cm³ - 1.6g/cm³ | ASTM D792 |
| Tensile Strength | Min 3.0 Mpa | ASTM D412 |
| Hardness | 65 +/- 5 Shore A | ASTM D2240 |
| Elongation at Break | ≥ 200% | ASTM D412 |
|
