EPDM 30% 50% 70% 100% content acid resistance rubber
Polymer: EPDM rubber
Color: Black
Thickness: Thickness ranges from 1mm to 100mm; above 15mm offered in sheet form.
Standard Size:
Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.
Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.
Customizable Shapes: Roll / Sheet / Strip
Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas
Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.
EPDM Acid Resistance Rubber Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation at Break |
| ZXZRS20011OR-PC30% | 1.4g/cm³ | 60+/-5 Shore A | 5Mpa | 200% |
| ZXZRS20011OR-PC50% | 1.4g/cm³ | 60+/-5 Shore A | 7-8Mpa | 350% |
| ZXZRS20011OR-PC70% | 1.35g/cm³ | 60+/-5 Shore A | 10Mpa | 400% |
| ZXZRS20011OR-PC100% | 1.3g/cm³ | 60+/-5 Shore A | 13Mpa | 450% |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1m | 10m | / | 10.4kgs/m² |
| 1.5 | 1m | 10m | / | 16.9kgs/m² |
| 1.7 | 1m | 10m | 1PLY | 19.5kgs/m² |
| 2 | 1m | 10m | 1PLY | 23.4kgs/m² |
| 3 | 1m | 10m | 1PLY | 36.4kgs/m² |
| 4 | 1m | 10m | 1PLY | 49.4kgs/m² |
| 5 | 1m | 10m | 2PLY | 62.4kgs/m² |
| 6 | 1m | 10m | 3PLY | 75.4kgs/m² |
| 8 | 1m | 10m | 4PLY | 101.4kgs/m² |
| 10 | 1m | 10m | 5PLY | 130kgs/m² |
| 12 | 1m | 2m | 8PLY | 31.2kgs/m² |
| 15 | 1m | 2m | 10PLY | 39kgs/m² |
| 20 | 1m | 2m | ≥10PLY | 52kgs/m² |
| 25 | 1m | 2m | ≥10PLY | 65kgs/m² |
1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.
Chemical Resistance Properties
| Polymer content | ZXZRS20011CR-PC20% | ZXZRS20011CR-PC30% | ZXZRS20011CR-PC50% | ZXZRS20011CR-PC70% | ZXZRS20011CR-PC100% |
| Aliphatic Hydrocarbons | Regular | Regular | Regular | Regular | Regular |
| Aromatic Hydrocarbons | Regular | Regular | Regular | Regular | Regular |
| Diluted Acids | Regular | Regular | Regular | Excellent | Excellent |
| Diluted Alkali | Regular | Regular | Regular | Regular | Excellent |
Note:
1. The chemical resistance values provided are intended as general reference only, based on standard laboratory conditions.
2. Actual performance may vary depending on chemical concentration, temperature, exposure time, and specific working conditions.
3. It is the responsibility of the user to verify material compatibility before application.
4. The manufacturer assumes no liability for damages or failures resulting from improper material selection or usage conditions.
5. Detailed technical advice are available upon request.
Tianjin China Rubber Co.,Ltd supplies an industrial-grade rubber sheet formulated for excellent EPDM acid resistance, offering long-term performance in chemically aggressive environments. Engineered with EPDM content ranging from 30% to 100%, this sheet adapts to varying resistance demands while maintaining mechanical integrity.
Known for superior ozone, UV, and chemical stability, EPDM ensures the rubber sheet resists degradation when exposed to acidic and alkaline substances. The formulation delivers balanced flexibility and tensile strength, making it ideal for gasket fabrication, chemical tank liners, and protective padding for acid-handling equipment. EPDM acid resistance properties are especially beneficial in wastewater treatment, electroplating, fertilizer manufacturing, and outdoor chemical storage. This rubber sheet remains flexible under temperature fluctuations and humid or corrosive conditions, extending service life and reducing maintenance.
When produced with higher EPDM content, the material performs consistently even under extended exposure to acids and alkalis. The epdm acid resistance makes it a trusted choice for protective sealing and barrier systems across chemical, industrial, and utility infrastructure projects.
