Product
Neoprene 30% 50% 70% 100% content acid resistant rubber sheet
Polymer: Neoprene rubber
Color: Black
Thickness: Thickness ranges from 1mm to 100mm; above 15mm offered in sheet form.
Standard Size:
Width: 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: 5mtrs 10mtrs 15mtrs 20mtrs; Custom dimensions available upon request.
Surface: Both sides smooth, or one/both sides with cloth, or one side with anti-slip texture.
Customizable Shapes: Roll / Sheet / Strip
Embedding layer: Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas
Packing Info: Custom packing includes plastic film, PP bags, and pallets.
Color, logo, and labels or special markings can be customized upon request.
Acid Resistant Rubber Sheet Performance Parameters & Specification
| Code | Specific Gravity | Hardness | Tensile Strength | Elongation at Break |
| ZXZRS20011CR-PC100% | 1.3g/cm³ | 60+/-5 Shore A | 10-12Mpa | 420% |
| ZXZRS20011CR-PC70% | 1.3g/cm³ | 60+/-5 Shore A | 9-10Mpa | 380% |
| ZXZRS20011CR-PC50% | 1.4g/cm³ | 60+/-5 Shore A | 7-8Mpa | 320% |
| ZXZRS20011CR-PC30% | 1.4g/cm³ | 60+/-5 Shore A | 5Mpa | 280% |
| Thickness | Width | Length | Insertion | Weight |
| 1 | 1m | 10m | / | 10.4kgs/m² |
| 1.5 | 1m | 10m | / | 16.9kgs/m² |
| 1.7 | 1m | 10m | 1PLY | 19.5kgs/m² |
| 2 | 1m | 10m | 1PLY | 23.4kgs/m² |
| 3 | 1m | 10m | 1PLY | 36.4kgs/m² |
| 4 | 1m | 10m | 1PLY | 49.4kgs/m² |
| 5 | 1m | 10m | 2PLY | 62.4kgs/m² |
| 6 | 1m | 10m | 3PLY | 75.4kgs/m² |
| 8 | 1m | 10m | 4PLY | 101.4kgs/m² |
| 10 | 1m | 10m | 5PLY | 130kgs/m² |
| 12 | 1m | 2m | 8PLY | 31.2kgs/m² |
| 15 | 1m | 2m | 10PLY | 39kgs/m² |
| 20 | 1m | 2m | ≥10PLY | 52kgs/m² |
| 25 | 1m | 2m | ≥10PLY | 65kgs/m² |
1. All specifications and dimensions above are subject to standard ± tolerances.
2. All data are provided as typical values within specified ranges; actual available specifications may vary depending on standard production grades.
3. This data sheet applies only to the rubber sheet products listed in the table. Other specifications can be manufactured upon request.
4. The weights provided in the table are theoretical values, actual product weights may vary due to production tolerances. In the case of customized rubber sheets, variations in width, length, thickness, or other specified parameters will impact the final weight. For reference only.
Chemical Resistance Properties
| Polymer content | ZXZRS20011CR-PC20% | ZXZRS20011CR-PC30% | ZXZRS20011CR-PC50% | ZXZRS20011CR-PC70% | ZXZRS20011CR-PC100% |
| Aliphatic Hydrocarbons | Regular | Regular | Excellent | Excellent | Excellent |
| Aromatic Hydrocarbons | Regular | Regular | Excellent | Excellent | Excellent |
| Diluted Acids | Regular | Regular | Regular | Excellent | Excellent |
| Diluted Alkali | Regular | Regular | Regular | Excellent | Excellent |
Note:
1. The chemical resistance values provided are intended as general reference only, based on standard laboratory conditions.
2. Actual performance may vary depending on chemical concentration, temperature, exposure time, and specific working conditions.
3. It is the responsibility of the user to verify material compatibility before application.
4. The manufacturer assumes no liability for damages or failures resulting from improper material selection or usage conditions.
5. Detailed technical advice are available upon request.
Tianjin China Rubber Co.,Ltd offers a specialized acid resistant rubber sheet manufactured using chloroprene (CR) as the base polymer, combined with reinforcing agents to meet varying chemical resistance needs. This sheet is engineered for environments where exposure to acids, alkalis, and corrosive fluids is common. CR content is customizable—30%, 50%, 70%, and 100%—to allow tailored resistance levels depending on the specific working medium. Higher chloroprene content ensures stronger protection against acid degradation, ozone, and weathering, while maintaining dimensional stability and mechanical resilience.
This acid resistant rubber performs well in a range of industrial applications such as chemical plant linings, storage tank pads, pipe insulation, and sealing components in harsh chemical environments. It offers consistent shielding from chemical corrosion without compromising elasticity or durability. The formulation ensures that the acid resistant rubber remains flexible at moderate temperatures while retaining structure under pressure and contact with various solvents. This makes it a reliable choice for chemical sealing, pump housings, barrier layers, and laboratory insulation setups.
